Supply PCZ Hammer Crusher20081105

Luoyang UTURN Machinary Co., Ltd.
This series of crusher applies to the middle broken brittle hardness of materials, such as coking coal, salt, chalk, alum, small pieces of limestone. gypsum, etc., were broken materials shall not be greater than the compressive strength of 150 MPa, water not more than 10 percent. PCZ series vertical shaft fine impacter
Main technical data:
Model No. PCZ0604 PCZ0608 PCZ0612 PCZ0808 PCZ0812 PCZ1012 PCZ1212
Rotor diameter mm 620 620 620 820 820 1020 1250
Rotor length mm 390 790 1190 790 1190 1190 1250
Rotor speed r/min 1000 1000 1000 1000 1000 750 650
Weight of hammer kg 24 24 24 28 28 28 40
Quantity of hammer 3 6 9 8 12 18 15
Max. feed size mm 150 250 250 350 350 350 350
Discharge size mm 10 10 10 15 15 3 15 3 20 3
Capacity t/h 5-15 15-25 30-40 40-50 50-60 26 60-90 27.6 100-140 31
Feed inlet size mm 440×440 440×800 440×1200 520×810 550×1200 550×1210 550×1270
Motor Power kw 15-18.5 45 55 75 90 132 185
Weight   kg 1670 2788 3675 4430 5835 7790 10500
