Laser engraving machine for leather shoes
|
| Place of Origin: |
China |
| ProductModel: | ZJ (3D)-6060 | | Brand Name: | Goldenlaser | | Payment Terms: | L/C,T/T | | Payment Terms: | | | Packing: | wooden package | | Minimum Order: | 1 set | | Delivery Time: | 15 workdays | | Supply Ability: | 5000sets/year | | Certificates: | CE,FDA,ISO9001 |
 |
- Country/Territory: ,China (Mainland)
- Business Type: Manufacturer
- No. of Total Employees:
|
 |
|
 |
|
Detailed Product Description
Laser engraving machine for leather shoes
Product Feature
1, Customize-design for the suitcase material engraving and punching
2,It adopt international advanced 3-dimension dynamic galvo control system.which could realize highly-speed engraving and punching on all kinds of suitcase material.
3,Equipped with red light position and Z axis auto up and down system.Also,it is possible to select the most slim spot,strongest laser beam,accuratest positioning way to process according to processing area.
Application Field
Suitable for all kinds of fur,leather fabric.
Technical Parameter
Laser type CO2 RF Metal laser tube
Laser power 150W
Working area 250mm*250mm--600mm*600mm for choice
Working table Zinc honeycomb working table
Cutting(no-load)speed 0-420000mm/min
Positioning accuracy 0.1mm
Moving system 3-Dimension Dynamic offline control system,5 inch LCD display
Cooling system Constant temperature water chiller
Power supply AC220V
Format support AI,BMP,PLT,DXF,DST etc
Standard collocation Two 1100W exhaust fans, foot switch
select collocation CO2 RF Metal laser tube(100W), red cross light location system
