TAIMES 3206D SOLVENT PRINTER
Printhead: SPT255-35PL
Number of Printhead: 6 Heads
Maximum Print Width: 3200mm
Print Mode Standard Output (m2 /h)
240x540dpi 3pass 19.90
240x720dpi 4pass 15.30
240x540dpi 6pass 10.55
360x540dpi 3pass 14.67
360x720dpi 4pass 11.21
360x540dpi 6pass 7.66
360x720dpi 8pass 5.74
Ink
Type : Solvent Ink / ECO-Solvent Ink
Color : 6 Colors( C , M , Y , K , Lc , Lm )
Capacity : 5L Per Main Tank of Each Color
Ink Supply System : Low Ink Detector, Auto or Manual Ink Supply System
Auto Media Feeding System: Equipped ( Max. Media Weight 80kg )
Auto Cleaning System: Positive Pressure Cleaning; Anti-clogged Flash Function &
Capping System
Pre-heating & Drying System: Equipped
Clamp: Equipped
Print Interface: USB2.0
Printhead Height: 2 to 4 mm Above Media Adjustable
RIP Software: Maintop , UltraPrint , PhotoPrint , Topaz , Wasatch , Caldera
Input Power: AC 220V ,50Hz/60Hz
Machine Dimension: L4,300 x W800 x H1,160 mm Net Weight : 340Kg
Package Dimension: L4,500 x W1,100 x H900 mm Gross Weight : 420Kg
Operation Environment: Temperature: 20~28 o C Humidity: 40%~60%
Advance Technic:
* Original Japanese drop on demand piezo print head with steel plate protected, 255 active nozzles
* 6 color plus 720dpi makes unmatchable color and high resolution.
* The voltage of the print head, automatically adjustable to the temperature, prevents blockage caused by the change of temperature.
* The function of skipping white space is added to increase productivity.
* The adjustment of bi-direction, step and carriage moving speed can be made during printing.
* Edge feather function can blur the pass line and feather the pass edge.
* Delicately designed alloy-aluminum platform.
