Vinyl plotter Model CT-1200
1. The appearance design of the patent, streamlined fuselage, carry the putting type control panel, easy to operate, elegant appearance. The keyboard is more durable than the old model.
2. Adopting the new micro step to subdivide algorithms, being in highly cutting quality while cutting at a high speed, the curve is smooth and more evasive.
Vinyl plotter CT-1200 Features
1.The appearance design of the patent, streamlined fuselage, carry the putting type control panel, easy to operate, elegant appearance.
2.Adopting new micro step to subdivide algorithms, being in highly cutting quality while cutting at a high speed, the curve is smooth and more evasive.
3.Softwae has the capacity to adjust the cutting precision to solve and prolong the inconsistent problems of size differently when all kinds of materials of malleability are cut.
4.Improve shock attenuation and subdue the sound device, reduce the noise further, but the power of the motor is not reduced.
5.Advanced industrial aluminum alloy fuselage, the surface is not worn and torn to fade through special-purpose processing.
6. Pairs of layering pairs of knife location, besides layering originally, set up half hob one, can is it is it carry heat of adhesive tape is it print paper, clothing pattern, etc. to transfer to have to cut. *
7. Leather card special purpose interface software, can accept AUTOCAD, CORELDRAW file that software output, can establish partial is it compensate with the corner compensating to close, needn't carve characters software can carve characters directly specially. *
8. Passing national security, performance and environment test in an all-round way, ISO9001 international quality certification system is made, performance is more reliable
Note: Hitting * items needs to especially order
Vinyl Cutter CT-1200 Parameters:
Type: CT-1200
Paper Feeding mode: Floor stand
Controller: 16 bit CPU, 1m cache ram16 bit CPU,1MB High-speed CACHE memory
Control panel: Over-head, 2x8 L C D, 13-button touch thin-film keyboard
Driver: High stepping motor, micro-step driver
Maximum paper Feed width: 1300mm
Max cutting width: 1195mm
Max cutting speed: 400mm/s
Max cutting length 20000mm<=20
Max cutting thickness: 1mm
Knife press: 0-400g(digital adjustment)
Mechanism precision: 0.1mm
Repeatable precision: +-0.1mm
Blade type: Carbide blade
Type of plot pen: All types Diameter 11.4mm plotter pen
