XGT-120 AUTOMATIC PLASTIC INJECTION MOLDING SHOE MACHINE
Specifications:
Brand: Xinguang
Model: XGT-120
Descriptions:
Main Features:
1) This plastic injection molding machine is specialized in the manufacture of thermoplastic TPU, TPR and PVC plastic soles, foaming and non-foaming, injection molding.
2) Full automatic computer program control and non-attended operation help to save human force and time, low in noise; and low-rotation and high-torque oil-pressure motor-driven feedstock drawing device, and extremely strong in variable speed control pressure.
3) Adopted large-diameter screw makes material injection large and production high; and computer digital is used to automatically control multi-station pressure setting, and injection molding can be achieved in different quantities about 20 kinds.
4) Its production rate is approximately 160 pairs per hour.
5) Rapid injection unit can be installed to produce ultra-light high foam PVC and TPR shoes.
Plastic Injection Molding Machine's Technical parameters:
Injection screw diameter 75mm
Injection capacity 880m3/shot
Electric hearing capacity 10Kw
Temperature control 4Point
Rotating speed of screw 0-200r.p.m
Torque of screw oil pressure 160kg.m
Injection distance 200mm
Power of motor 22Kw
Mould clamping force 60ton
Max. mould quantity 20
Max. mould size 500*200*200(mm)
Net weight 4.2ton
Dimension 4.3*2.0*2.0m
