Technical Description
Item Unit
Raw material PVC.TPR
Work Stations Stations 24
Mould-clamping Pressure Kg 70000
Space to hold mould Mm (LxWxH) 400*200*220 / 600*280*230
Diameter of Screw Mm 60
Max. Injection Volume Cm3 758 / 785
Injection Pressure Kg/cm2 550
Diameter of Disc m 3.60
Temperature Control Section Sections 4
Electric Heating Energy of Material tube Kw 8.78 / 9.18
Motor Kw/Hp 18.5/25
Total Electricity Consumption kw 29
Machine Size
Mm 5500*2980*2000 / 6200*3530*2300
Output Pairs/day 2500
Machine Weight kg 6800 or 8800
Feature:
1 most of mechanical movements, covering ranges from injection, feeding, disc-rotating to mould-clamping, could be inputted into PLC, which ensures more accuracy for mechanical movements.
2 equipped with digital-type proportional controller so as to control mould-clamping pressure, injection pressure and feeding pressure.
3 unique mechanical structure, which allows to place big mould in size; at the same time, the machine is fitted with mould cooling device which is easy to operate, producing product more perfectly.
4 with the help of blowing system, the machine can have product lightweight, soft and own a polished looking in surface. Besides, the weight can be 20%-30% lower than traditional production way.
5 recycled material can be mixed together to produce products, quality of which can be comparable with new product made of purely new material.
